- Size: 865*728*1240mm
- Place of Origin: Henan, China (Mainland)
- Brand Name: Nanbei
- Model Number: GL-20
- Weight: 235.000 kg
Features:
1.Brushless frequency motor which in great torque, free maintenance, no powder pollution, quick in speed up and down.
2.The flexible axle driven system which drive the rotor directly, smooth in operation, low noise and small vibration.
3.Import compressors fluorine free, double cycle cooling, cold and hot alternating easily, free environment pollution and precise in temperature control.
4.More than 20 kinds of rotors for your choice,especial the continuous rotors which help you purify a large number of test solution continuously.
5.Micro computer control system, digital display the temperature, time and speed. There are 10 kinds of program and 10 kinds of acceleration and deceleration for your choice.
6.Automatically eletric lid lock, super speed, over temperature protection and imbalance protection.
7.The centrifuge body is made of high-quality steel, safe and reliable.
Technical parameters:(GL21M/GL21MC):
Max speed | 21000r/min |
Max Volume | 6*500ml |
Timer | 1-99h59min |
Dimesion | 865*728*1240mm |
Speed accuracy | ±20r/min |
Temperature Accuracy | ±1°C |
Max RCF | 46140*g |
Temperature Range | -20°C-40°C |
Noise | ≤65dBA |
Net weight | 235kg |
Power supply | AC220v 50HZ 20A |
Matched Rotors:
No | Rotors No | Max speed r/min | Volume Ml | Max RCF |
No30108 | Fixed rotor | 21000 | 12*10ml | 44440 |
No30117 | Fixed rotor | 20000 | 16*10ml | 46140 |
No30111 | Fixed rotor | 20000 | 6*50ml | 44700 |
No30118 | Fixed rotor | 20000 | 8*30/20ml | 42040 |
No30119 | Fixed rotor | 15000 | 8*50ml | 27540 |
No30112 | Fixed rotor | 15000 | 6*70ml | 25480 |
No30120 | Fixed rotor | 12000 | 8*100ml | 19610 |
No30121 | Fixed rotor | 11000 | 4*300ml | 18120 |
No30122 | Fixed rotor | 10000 | 6*300ml | 15730 |
No30123 | Fixed rotor | 10000 | 6*500ml | 18340 |
No30132 | Interval rotor | 17000 | 1000ml | 31390 |
No30133 | Interval rotor | 12000 | 1200ml | 19350 |
No30134 | Interval rotor | 10000 | 3000ml | 14890 |
No30135 | Vertical rotor | 20000 | 16*5ml | 38340 |
No30136 | 18000 | 8*30ml | 32650 | |
No30180 | Swing rotor | 15000 | 4*5ml | 21670 |
No30181 | 13000 | 4*30ml | 23580 | |
No30182 | 10000 | 4*50ml | 16240 | |
No30694 | Bucket rotor | 4000 | 4*4*96well | 2840 |
No30696 | Swing rotor | 4000 | 4*750ml(500mlbottle) | 3380 |
Matched for the 40301-40308 adaptor | ||||
No. | Rotors No. | Max speed r/min | Volume(ml) | Max RCF | Standard flow | Deposit |
No30128 | Continuous centrifuge rotor | 17000 | 1000ml | 31390 | 285-350ml/s | 500ml |
No30129 | Continuous centrifuge rotor | 14000 | 1800ml | 21710 | 220-500ml/s | 500ml |
No30130 | Continuous centrifuge rotor | 8000 | 3000ml | 9450 | 220-500ml/s | 1600ml |
No30131 | Continuous centrifuge rotor | 8000 | 1800ml | 8600 | 220-500ml/s | 1000ml |
